Silva 70P Small Boat Compass
Silva 70P Small Boat Compass
Couldn't load pickup availability
70P is a bulkhead mount compass designed for yachtsmen that demand absolute accuracy and a steady card in all conditions
The compass handles unlimited slope of the keel line and a 30º heeling angle. The curved lubber line enables swift and clear reading at a glance without parallax errors. With a main steering scale on the horizontal part and direct reading on the vertical edge,
70P is ideal for boats with a sitting as well as a standing helmsman. It can be mounted at most angles and its compact size (70 mm) makes it suitable for smaller boats.
FEATURES
- Double scales - Can be read from front and above
- Suitable for all boats - Fits in all boat types
- Curved lubber lines - Accurate reading from different angles
- Compact size - Small and flexible
| Accuracy |
± 1° (17.8 mils) |
|---|---|
| Apparent card diameter |
70mm |
| Built-in compensator |
Optional |
| Card type |
Cone |
| Compatibility |
Kayaks, powerboats, sailboats |
| Size |
95x72 mm |
| Heeling angle |
Roll: 30° Pitch: 30° |
| Heeling angle scale |
No |
| Illumination |
Optional |
| Lubber lines |
Centre |
| Material |
ABS, Acrylic |
| Memory ring |
No |
| Mounting |
Rubber straps |
| Mounting angle |
-10° to +100 |
| Protective cover |
No |
| Temperature operating range |
-10°C to +70°C |
| Type of compass |
Steering compass |
| Variant |
Magnetic North |
| Water resistance |
Waterproof |
| Weight |
344g |
